Wire Rod – EC Electric Aluminum Redraw Rod

JSK Aluminum Rod for Electrical Applications

JSK aluminum rod is engineered for superior electrical performance, meeting or exceeding industry standards. These high-quality rods are widely used in power transmission, electrical wiring, and industrial applications, ensuring optimal conductivity and durability.

JSK aluminum rod complies with the following ASTM standards:

ProductSpecification
B-211Aluminum and Aluminum Alloy Bar, Rod and Wire
B-233Aluminum Rod, 1350-H12, 1350-H14, 1350-H16 Drawing Stock.
B-398Aluminum Alloy 6201 Drawing Stock.
B-531Aluminum Alloy 5005 Drawing Stock.
B-800Standard Specification for 8000 Series.

JSK manufactures aluminum rods according to international standards (BS, DIN, IEC, NFC, etc.) upon request. The following are the principal aluminum rod products available:

ProductSpecification
EC-1350Rod with conductivity in a range of 61 % to 63% IACS, and from 60 N/mm2 Up to 150 N/mm2.
5005Rod with a minimum conductivity of 53.8% IACS, and from 95 N/mm2 up to 200 N/mm2.
6101Rod with a conductivity of 50.5% up to 53% IACS, and from 160 N/mm2 Up to 220 N/mm2. JSK's continuous casting line also features continuous heat-treated 6101 rod.
6201Rod with a conductivity of 50.5% up to 52.0% IACS, and from 170 N/mm2 Up to 230 N/mm2.
8017Rod with a minimum conductivity of 58.5% up to 60.8% IACS, and from 115 N/mm2 to 140 N/mm2.

JSK aluminum rod ensures maximum electrical efficiency, meeting diverse industry needs with premium quality and precision.

JSK  aluminum rod for electrical purposes meets or exceed the following ASTM specifications:

ProductSpecification
B-211Aluminum and Aluminum Alloy Bar, Rod and Wire
B-233Aluminum Rod, 1350-H12, 1350-H14, 1350-H16 Drawing Stock.
B-398Aluminum Alloy 6201 Drawing Stock.
B-531Aluminum Alloy 5005 Drawing Stock.
B-800Standard Specification for 8000 Series.
JSK manufactures aluminium rod according to all international standards (BS, DIN, IEC, NFC etc) upon request. The following are the principal products being marketed:
ProductSpecification
EC-1350Rod with conductivity in a range of 61 % to 63% IACS, and from 60 N/mm2 Up to 150 N/mm2.
5005Rod with a minimum conductivity of 53.8% IACS, and from 95 N/mm2 up to 200 N/mm2.
6101Rod with a conductivity of 50.5% up to 53% IACS, and from 160 N/mm2 Up to 220 N/mm2. JSK's continuous casting line also features continuous heat-treated 6101 rod.
6201Rod with a conductivity of 50.5% up to 52.0% IACS, and from 170 N/mm2 Up to 230 N/mm2.
8017Rod with a minimum conductivity of 58.5% up to 60.8% IACS, and from 115 N/mm2 to 140 N/mm2.
